Acoustic Wood Slat Wall Panels

Acoustic Wood Slat Wall Panels

Bring the warmth of wood texture to interior walls and ceilings with CARSEM acoustic wood slat wall panels. Slatted and decorative profiles pair MDF or black HDF with PET fiber backing, with face finishes available in paper, natural or technical wood veneer, PVC film and other collection options.

Construction & Finish Options

• Core: MDF board or black HDF board, according to the selected model.

• Backing: PET fiber on the acoustic constructions shown in the supplied product details.

• Surface: paper, natural/technical veneer, PVC film, melamine, solid color, marble or metal-effect options by collection.

• Designs: linear slat profiles, geometric patterns and modular decorative panels.

Sizes Shown in the Product Details

Multiple series are documented, so dimensions should be matched to the chosen profile. The MDF/black HDF + PET construction sheet lists 21 or 24 mm thickness, widths of 285, 305 or 605 mm, and lengths from 2400 to 3000 mm. A separate slat-system sheet shows a 20 mm example build (11 mm MDF + 9 mm PET), widths of 280/400/600 mm, and lengths from 600 to 3050 mm. Decorative and modular models include other dimensions and 18 or 21 mm options. Confirm the model drawing before order.

Acoustic Test Information

The supplied materials include a test reference listing NRC 0.75 and a separate sheet showing Class A absorption to EN ISO 354:2003. These results apply to their tested construction and setup, not automatically to every profile. Ask us for the report matching the selected panel, backing, cavity and installation method.

Applications

Use acoustic wood panels in living rooms, bedrooms, media rooms, hotel interiors, offices, reception areas, restaurants, showrooms and other interior fit-outs. Confirm fixing method and substrate for the intended wall or ceiling application.

Request Samples & a Quote

Send your project location, estimated quantity, preferred finish, profile and target dimensions. We will help identify the matching series and confirm current specifications, sample availability and project pricing.

Frequently Asked Questions

Are all panel sizes the same?

No. The supplied sheets cover multiple series and profile-specific dimensions. Confirm your chosen model before production.

Can I request a specific wood-look finish?

Yes, finishes vary by collection. Ask for current color options and samples to review before selection.

Does NRC 0.75 apply to every design?

No. It is listed on a supplied test reference for one setup. Request the test report for the exact construction and installation planned.
