CMC006
OEM/ODM/CARSEM
| Sizes:: | |
|---|---|
| Wear Layer:: | |
| UV Coating:: | |
| Thickness:: | |
Product Description
This Texture is more smooth and flat. It is very popular texture on clean designed patterns.
This Texture looks more stone looking, and very deep. It is suitable for thickness of vinyl flooring which is more than 4.0mm.
This Texture is the most popular texture on SPC, WPC and Vinyl flooring.
| Brand Name | OEM/ODM/CARSEM | Design | Carpet Vinyl Flooring |
| Material | Resin PVC, Calcium carbonate（Grade A）,Stabilizer(environmental) | Usage | Indoor |
| UV Coating Options | Ceramic Bead/Anti-microbial/Anti-Stain | Thickness | 2.0mm to 6mm |
| Backing Options | 1mm to 2mm IXPE/EVA/Cork underlayment | Gloss Level | Matt, Glossy |
| Bevel Treatment | Micro bevel, Painted bevel, Tru-Grout | ||
| Product Name | Vinyl Flooring for indoor | Feature | Waterproof Wear Resistant Anti-slip |
| Certificate | ISO9001, ISO14001, CE, Floor Score, SGS, VOC, TUV, Greenguard Golden | Click System | Dry back, loose lay, Click System |
| Packing method | Carton, solid wood pallet | Advantage | Eco-friendly / 100% Waterproof |
Room Scene
Room Scene
Room Scene
Room Scene
Room Scene
Room Scene
Room Scene
Room Scene
Room Scene
Technical Data
| Factory's Test Items | Factory's Standards | Testing Method |
| Flaw, Crack, Wrinkle, Hold, Separating | Not Allowed | GB4085-83 |
| Color Difference | Two Tones Allowed | GB4085-83 |
| Dirt, Color Change | Not Easily Noticeable | GB4085-83 |
| Specifications | ||
| Length Measurement | ± 0.1mm(≤6") | EN427 |
| ± 0.3mm(12" ~ 24") | ||
| ± 0.5mm(≥36") | ||
| Overall Thickness | ± 0.15mm | EN428 |
| Squareness | ≤0.25mm | EN427 |
| Straightness | ≤0.25mm | EN427 |
| Physical Statistics | ||
| Dimensional Stability to Heat | ≤0.12% | EN434 |
| (80℃, 6Hrs) | ||
| Curling After Exposure To Heat | ≤1.2mm | EN434 |
| (80℃, 6Hrs) | ||
| Wear Resistance | ≤0.015g | EN-660-2 |
| Peel Resistance | ≥2.8Kgf/2cm | EN431 |
| Residual Indentation After Static Loading | ≤0.1mm | EN434 |
| Flexibility | No Damage | EN435 |
| All products comply to EN 14041:2004 Safety Standards | ||
| Product Specifications | Standard | Testing Method |
| Reaction to Fire | Class Bf1-s1 | EN717-1 |
| Formaldehyde Emission | Not Detected | EN717-1 |
| Determination of migration of heavy metals | Not Detected | EN71 |
| Effect of a caster chair | Pass | EN425 |
| Color Fastness to Light | Grade(Blue Wool Std):6 | EN ISO 105 B02 |
