CMP1010
OEM/ODM/CARSEM
Size: | |
---|---|
Thickness:: | |
Wear Layer:: | |
UV Coating:: | |
Bevels: | |
Availability: | |
Product Description
Our factory has 20+ collections and 200+ designs and colors of E.I.R texture options.
This texture is widely used on wood designs of vinyl flooring.
This texture has Min. thickness inquiry from 4.5mm
This texture is the most popular texture on vinyl flooring.
Brand Name | OEM/ODM/CARSEM | Design | Vinyl Plank Flooring |
Material | Resin PVC, Calcium carbonate(Grade A,Stabilizer(environmental) | Usage | Indoor |
UV Coating Options | Ceramic Bead/Anti-microbial/Anti-Stain | Thickness | 2.0mm to 5.0mm |
Backing Options | 1mm to 2mm IXPE/EVA/Cork underlayment | Gloss Level | Matt, Glossy |
Bevel Treatment | Micro bevel, Painted bevel | Density | 1300kgs/M3 |
Product Name | Plastic Vinyl Flooring for indoor | Feature | Waterproof,Wear Resistant,Anti-slip |
Certificate | ISO9001, ISO14001, CE, Floor Score, SGS, VOC, TUV, Greenguard | 4 Sides | Dryback, loose lay, Click System |
Packing method | Carton, solid wood pallet | Advantage | Eco-friendly / 100% Waterproof |
Technical Data
Factory's Test Items | Factory's Standards | Testing Method |
Flaw, Crack, Wrinkle, Hold, Separating | Not Allowed | GB4085-83 |
Color Difference | Two Tones Allowed | GB4085-83 |
Dirt, Color Change | Not Easily Noticeable | GB4085-83 |
Specifications | ||
Length Measurement | ± 0.1mm(≤6") | EN427 |
± 0.3mm(12" ~ 24") | ||
± 0.5mm(≥36") | ||
Overall Thickness | ± 0.15mm | EN428 |
Squareness | ≤0.25mm | EN427 |
Straightness | ≤0.25mm | EN427 |
Physical Statistics | ||
Dimensional Stability to Heat | ≤0.12% | EN434 |
(80℃, 6Hrs) | ||
Curling After Exposure To Heat | ≤1.2mm | EN434 |
(80℃, 6Hrs) | ||
Wear Resistance | ≤0.015g | EN-660-2 |
Peel Resistance | ≥2.8Kgf/2cm | EN431 |
Residual Indentation After Static Loading | ≤0.1mm | EN434 |
Flexibility | No Damage | EN435 |
All products comply to EN 14041:2004 Safety Standards | ||
Product Specifications | Standard | Testing Method |
Reaction to Fire | Class Bf1-s1 | EN717-1 |
Formaldehyde Emission | Not Detected | EN717-1 |
Determination of migration of heavy metals | Not Detected | EN71 |
Effect of a caster chair | Pass | EN425 |
Color Fastness to Light | Grade(Blue Wool Std):6 | EN ISO 105 B02 |
