Product Description

SPC Grout Line Tile Texture Options:

Pocket embossment

Pocket Emboss

This Texture is more smooth and flat. It is very popular texture on clean designed patterns SPC Flooring.

Slate emboss

Slate Emboss

This Texture looks more stone looking, and very deep. It is suitable for thickness of SPC flooring which is more than 4.5mm.

Coral embossment

Coral Emboss

This Texture is the most popular texture on tile design SPC, WPC and Vinyl flooring. It looks very vivid.

Brand Name OEM/ODM/CARSEM Design Grout Line Tile SPC Vinyl Flooring
Material

Resin PVC, Calcium carbonate(Grade A),Stabilizer(environmental

Usage Indoor
UV Coating Options Ceramic Bead/Anti-microbial/Anti-Stain Thickness 5.5mm and more
Backing Options 1mm to 2mm IXPE/EVA/Cork underlayment Gloss Level Matt, Glossy
Bevel Treatment True-Grout Density

2000kgs/M3

Product Name SPC Vinyl Flooring for indoor Feature Waterproof Wear Resistant Anti-slip
Certificate ISO9001, ISO14001, CE, Floor Score, SGS, VOC, TUV, Greenguard Golden Click System Click System
Packing method Carton, solid wood pallet Advantage Eco-friendly / 100% Waterproof



Technical Data

Factory's Test ItemsFactory's StandardsTesting Method
Flaw, Crack, Wrinkle, Hold, SeparatingNot   AllowedGB4085-83
Color DifferenceTwo   Tones AllowedGB4085-83
Dirt, Color ChangeNot   Easily NoticeableGB4085-83
Specifications
Length Measurement±   0.1mm(≤6")EN427
± 0.3mm(12" ~ 24")
± 0.5mm(≥36")
Overall Thickness±   0.15mmEN428
Squareness≤0.25mmEN427
Straightness≤0.25mmEN427
Physical Statistics
Dimensional Stability to Heat≤0.12%EN434
(80℃, 6Hrs)
Curling After Exposure To Heat≤1.2mmEN434
(80℃, 6Hrs)
Wear Resistance≤0.015gEN-660-2
Peel Resistance≥2.8Kgf/2cmEN431
Residual Indentation After Static Loading≤0.1mmEN434
FlexibilityNo   DamageEN435
All products comply to EN 14041:2004 Safety   Standards
Product SpecificationsStandardTesting   Method
Reaction to FireClass   Bf1-s1EN717-1
Formaldehyde EmissionNot   DetectedEN717-1
Determination of migration of heavy metalsNot   DetectedEN71
Effect of a caster chairPassEN425
Color Fastness to LightGrade(Blue   Wool Std):6EN   ISO 105 B02
